Retaining walls design- MDC

390.00 exc. VAT

(10 customer reviews)

MDC is a software for the design and analysis of retaining walls in: reinforced concrete, gravity, block, gabions walls, with direct or pile foundations and with anchors.

The geotechnical computation employs the standard geotechnical methods subject to user choice and carries out the verifications prescribed by the selected standard, amongst which global stability even in seismic conditions. Structural evaluations perform reinforcement sizing and verification with Ultimate Limit State or Allowable Tensions.

MDC is simple and intuitive but with unique features, including pre-design work, easy management of the combinations: GEO, STR, GLOBAL STABILITY, localization and automatic import of seismic parameters, displacements analysis in a dynamic field, reinforcements editor, import and export of works that should fall in stabilization operations.

Video tutorial

Help

Description

Software for the design and analysis of retaining walls in: reinforced concrete, gravity, gabions, blocks with direct foundation or on piles, possibly supported by tie rods. Thanks to the various options available, the program allows you to deal with reinforced concrete, gravity, block and gabion walls:

    • Reinforced concrete walls;
    • Gravity walls;
    • Gabion Walls;
    • Block Walls;
    • Walls supported on piles or mini piles;
    • Walls with tiebacks/anchors;
    • Walls with a shelf on the uphill side;
    • Footing keys;
    • The stepped wall on the uphill side;
    • Tapered profile (stem and footing) on both sides;
    • Forces acting on the wall: FX, FY, MZ on n points;
    • Layered terrain;
    • Backfill;
    • Loads on backfill;
    • Inclined terrain on uphill and downhill sides;
    • Groundwater or confined water layers;
    • Drainage insertion on the uphill side;
    • Fixed head walls;
    • Stress diagrams;
    • Global stability analysis using several methods: Fellenius, Bishop, Janbu, Bell,
    • Sarma, Morgenstern & Price, D.E.M., Zeng Liang.

Supported computation standards:

    • Eurocode 7/8
    • NTC
    • STAS
    • British Codes BS8004/BS8110
    • SR EN 1997-1 Anexa RO / EC2: SR EN 1992-1-1 / Normativul pentru proiectarea lucrarilor de sustinere (Anexa A)

The unique feature of this software is the simplicity with which you can manage various combinations of loads summarizing in a single phase, both load conditions and computation.

STRATIGRAPHY

Simple layer declaration allows any layers to be modelled on uphill and downhill sides of the wall with individual inclinations. Mouse click and drag allow layer boundaries to be moved or inclined. Each layer is assigned the geotechnical parameters required for computation, and each may be associated with a colour and/or texture. An internal soil database, expandable and amendable by the user, simplifies these choices.

COMPUTATION

The user can choose one of the following methods for the computation of thrust: Coulomb, Rankine or Mononobe & Okabe. It is also possible to perform the calculation considering the thrust at rest and, for the elements subject to passive jab, to impose the percentage of mobilized thrust. The structural computation and analysis can be performed, at the user’s choice, with the Limit States or Allowable Tensions methods.

Trial & ChangeLog

TRIAL
It is possible to request a trial version of this product. To speed up software learning, you can also ask for a live demonstration session. This will allow you to determine if the product meets your requirements. Send an email to: info(at)geostru.eu.

Basic requirements of the system.

Educational version for students and teachers

How to download, install and activate the software

CHANGELOG

2024.31.8.1098

30/04/2024

New release 2023

2021.29.7.1024

26/09/2020

New release 2021

2020.29.7.1001

30/11/2019

Solved compatibility win10

2020.28.7.1000

26/09/2019

New version 2020

2019.28.7.999

18/06/2019

New Release 2019

2018.25.7.990

12/11/2018

New version 2018

2017.25.7.948

04/09/2017

Bug Fix in: Seismic capacity
News version 2017, compatible with win 10, general improvements, added New standards and bug fix

2016.25.7.914

11/09/2016

  • Changes in Hansen algorithm Export file for GFAS
  • Improved calculation structural algorithm
  • Optimization of calculation algorithm of the reinforcement for walls with stepped sections. For walls founded on piles, introduced a symbol for the check condition to limit vertical load.
  • Integrations on forces diagrams.
  • Modified the pressure diagrams. Integration on bearing capacity. Integration on computation report. Integration on global stability module's statement.
  • Implemented Hansen's method for the computation of bearing resistance.
  • Executed a new command for the advanced management of the vertices' coordinates of the wall section. Using this command will be possible to model many other types of walls. From the new command "Forces" can be seen the overturning and stabilizing actions on the border.
  • Revision of the diagrams of the increase in thrust due to the earthquake.
  • Wall section that protrudes from the ground, as for the fences. Enter the negative height for the barrier.
  • Application of loads at different sizes from the ground level.
  • Importing files from static and dynamic penetration tests. The files can be imported with direct commands or simple drag-and-drop operations on the workspace.
  • The files generated by our programs are open to editing with a text editor.
  • The import of penetration tests is a handy tool because dozens of geotechnical parameters are automatically converted regarding units of measurement.
  • By assigning a negative height to the dam is possible to lower the ground surface level behind the wall.
  • Complete review of the software in national and international versions.
  • Improvements in materials printing.
  • A new version is available.
  • Computation report integrated.
  • Progress on the editor of the computation report.

10 reviews for Retaining walls design- MDC

  1. Claudio (verified owner)

    Mi accodo ad altri utenti nella richiesta di un manuale d’uso più sostanzioso e con qualche esempio

  2. alessandro (verified owner)

    non chiarissima la gestione delle combinazioni di carico, occorrerebbe un manuale più dettagliato dell’help in linea attualmente disponibile, per una maggiore chiarezza su cosa fa il programma, e per niente chiara la possibilità di aggiornamento e scadenza degli aggiornamenti scaricabili, inserirei nel programma la possibilità di richiedere un aiuto in linea o tiket come ha ora la maggior parte del software, inserirei una libreria di tiranti, pregi semplicità di utilizzo, rapido da imparare

  3. Pasquale Totaro (verified owner)

    Software semplice e interattivo con una grafica efficace. Migliorerei la fase di gestione delle combinazioni di carico e la manualistica. L’assistenza con operatori molto gentili e competenti.

  4. Uliana Gianfranco (verified owner)

    Software con cui in generale mi trovo bene, a parte la gestione, ed il controllo, delle combinazioni di carico

  5. goristefano (verified owner)

    Mi trovo benissimo, anche a me farebbe piacere un manuale d’uso magari da stampare ma vale comunque 5 stelle!!!

  6. Teo Francesco Giorgi (verified owner)

    E’ auspicabile l’edizione di un manuale d’uso che completi il, troppo, stringato help presente nel programma

  7. Teo Francesco Giorgi (verified owner)

    E’ auspicabile un manuale d’uso perché l’help in linea non soddisfa i dubbi che sovvengono con l’uso del programma

  8. Francesco A.

    1) Sarebbe gradita una breve descrizione sul contenuto degli aggiornamenti e sulle modalità d’installazione (es. la versione precedente dev’essere disinstallata prima dell’installazione della versione aggiornata?).2) É molto fastidioso passando alla verifica della stabilità globale (Slope) rilevare la non corrispondenza fra alcuni dati del progetto (MDC). 3) Alcune parti delle istruzioni dovrebbero meglio chiarite (es. procedura di verifica).4) Non trovo corretto considerare la suola della fondazione (Muro a mensola) nella direzione longitudinale parallela al muro e normale al piano delle azioni interne, alla stregua di una trave di fondazione assegnando in tale direzione longitudinale l’armatura minima prescritta dalle NTC per questo tipo di strutture (0.20% Inf. + 0.20% sup) Ac!!. Sarebbe più corretto lasciare all’utente la la possibilità di stabilire autonomamente la percentuale d’armatura longitudinale e imporre, se necessarie, le armature minime nella sola direzione normale alla parete, parallela al piano delle azioni interne (M,T).

  9. g.bonadies (verified owner)

    Nonostante la licenza dei miei software scade il 2021 dopo un pò di tempo che non li usavo tutti i miei software non si attivano. Il PC è sempre lo stesso. Posso avere una risposta. Grazie

    • filippo catanzariti

      Buongiorno Giuseppe
      Abbiamo verificato lo stato delle sue licenze sono attive ma ci risulta che non ha scaricato le ultime versioni. Dalla sua area utente scarichi il software, li installi ed attivi con il codice che trova nella sua area utente. Se ha difficoltà contatti roxana@geostru.eu

  10. angelo (verified owner)

    un pò complicato nella definizione delle combinazioni di carico
